450W LED Module Beam Moving Head

Name: 450W LED Module Beam Moving Head
Brand: YL Light

450W LED Module Beam Moving Head is a stage lighting catalogue item in the moving head beam light category. Reference specifications list rated power: 450W; light source: 400W LED module; LED brand and model remain TO BE CONFIRMED. Confirm the exact fixture version, specifications and current supply details before ordering.

WHATSAPPRequest a Quote

View specifications

Light source: 400W LED module; LED brand and model remain TO BE CONFIRMED
Protection: IP20 indoor
Control modes: DMX512 / RDM / master-slave / auto / sound

Planning this product into your project

Start with the visual task and the distance from this fixture to the stage or subject. Compare its documented optics, movement, colour and control functions against that position in the lighting plan.

Product configuration

Movement: Pan 540 degrees / tilt 270 degrees / 16-bit fine channels
Product: 450W LED Module Beam Moving Head
Frost / rainbow: Dedicated frost / rainbow effect channel
Focus: Motorized focus
Packing: TO BE CONFIRMED

Optical performance

Rated power: 450W
Light source: 400W LED module; LED brand and model remain TO BE CONFIRMED
Color wheel: 8 colors + CTO + white; split-color effects
Fixed gobos: 15 fixed gobos + open; shake and rotation effects
Prism system: Independent 8-facet and 8+16-facet prisms with rotation
Beam angle: Beam angle remains TO BE CONFIRMED; isolated fixture metadata is not corroborated

Control and connections

DMX channels: 18CH DMX512; XML, D4 and R20 agree
Input voltage: AC100-240V, 50/60Hz
Control modes: DMX512 / RDM / master-slave / auto / sound

Construction and dimensions

Protection: IP20 indoor
Size / weight: TO BE CONFIRMED
Electrical protection: Rated current and fuse value, type and position remain TO BE CONFIRMED.

What to confirm for your quotation

Provide the throw distance, mounting height and beam or coverage required.
Confirm the exact light source, optical functions and channel mode for the quoted variant.
Request relevant photometric data and a demonstration using the intended colour and zoom settings.
Check power, connectors, weight, protection rating and the included mounting accessories.

TECHNICAL REFERENCE

Product specifications.

Published product details. Ask our team about any configuration that is not listed.

450W LED Module Beam Moving Head technical specifications
Rated power	450W
Light source	400W LED module; LED brand and model remain TO BE CONFIRMED
DMX channels	18CH DMX512; XML, D4 and R20 agree
Movement	Pan 540 degrees / tilt 270 degrees / 16-bit fine channels
Product	450W LED Module Beam Moving Head
Input voltage	AC100-240V, 50/60Hz
Control modes	DMX512 / RDM / master-slave / auto / sound
Color wheel	8 colors + CTO + white; split-color effects
Fixed gobos	15 fixed gobos + open; shake and rotation effects
Prism system	Independent 8-facet and 8+16-facet prisms with rotation
Frost / rainbow	Dedicated frost / rainbow effect channel
Focus	Motorized focus
Protection	IP20 indoor
Size / weight	TO BE CONFIRMED
Packing	TO BE CONFIRMED
Beam angle	Beam angle remains TO BE CONFIRMED; isolated fixture metadata is not corroborated
Electrical protection	Rated current and fuse value, type and position remain TO BE CONFIRMED.
