295W Beam Moving Head with LED Ring

Name: 295W Beam Moving Head with LED Ring
Brand: YL Light

295W Beam Moving Head with LED Ring is a stage lighting catalogue item in the moving head beam light category. Reference specifications list rated power: 450W; dmx channels: 16CH DMX512. Confirm the exact fixture version, specifications and current supply details before ordering.

WHATSAPPRequest a Quote

View specifications

Protection: IP20, professional indoor use
Control modes: DMX512 / sound / auto / master-slave
Size / weight: TO BE CONFIRMED

Planning this product into your project

Start with the visual task and the distance from this fixture to the stage or subject. Compare its documented optics, movement, colour and control functions against that position in the lighting plan.

Product configuration

Movement: Pan 540 degrees / tilt 270 degrees / fine channels
Product: 295W Moving Head Beam + LED Ring
LED ring: 30 imported LEDs; segmented chase and running patterns
Focus: Motorized focus
Dimming / strobe: 0-100% dimming; variable and random strobe

Optical performance

Rated power: 450W
Color wheel: 14 colors + white
Fixed gobos: 13 fixed gobos + open
Prism system: Two independent wheels: 8-facet + honeycomb; overlay
Frost / color effect: Frost and six-color insertion through CH8

Control and connections

DMX channels: 16CH DMX512
Input voltage: AC100-240V, 50/60Hz
Control modes: DMX512 / sound / auto / master-slave
Lamp control: Lamp off, lamp on and full motor reset on CH16

Construction and dimensions

Size / weight: TO BE CONFIRMED
Protection: IP20, professional indoor use
Electrical protection: Use a grounded supply. Rated current and fuse value must follow the product nameplate; the fuse holder is on the rear power p anel.

What to confirm for your quotation

Provide the throw distance, mounting height and beam or coverage required.
Confirm the exact light source, optical functions and channel mode for the quoted variant.
Request relevant photometric data and a demonstration using the intended colour and zoom settings.
Check power, connectors, weight, protection rating and the included mounting accessories.

TECHNICAL REFERENCE

Product specifications.

Published product details. Ask our team about any configuration that is not listed.

295W Beam Moving Head with LED Ring technical specifications
Rated power	450W
DMX channels	16CH DMX512
Movement	Pan 540 degrees / tilt 270 degrees / fine channels
Input voltage	AC100-240V, 50/60Hz
Product	295W Moving Head Beam + LED Ring
LED ring	30 imported LEDs; segmented chase and running patterns
Control modes	DMX512 / sound / auto / master-slave
Color wheel	14 colors + white
Fixed gobos	13 fixed gobos + open
Prism system	Two independent wheels: 8-facet + honeycomb; overlay
Frost / color effect	Frost and six-color insertion through CH8
Focus	Motorized focus
Dimming / strobe	0-100% dimming; variable and random strobe
Size / weight	TO BE CONFIRMED
Protection	IP20, professional indoor use
Lamp control	Lamp off, lamp on and full motor reset on CH16
Electrical protection	Use a grounded supply. Rated current and fuse value must follow the product nameplate; the fuse holder is on the rear power p anel.
