200W LED Module Beam Light with RGB Ring

Name: 200W LED Module Beam Light with RGB Ring
Brand: YL Light

200W LED Module Beam Light with RGB Ring is a stage lighting catalogue item in the moving head beam light category. Reference specifications list rated power: 200W; light source: LED module; exact brand, model and actual source wattage TO BE CONFIRMED. Confirm the exact fixture version, specifications and current supply details before ordering.

WHATSAPPRequest a Quote

View specifications

Light source: LED module; exact brand, model and actual source wattage TO BE CONFIRMED
Electrical protection: Use a grounded supply. Rated current and fuse value, type and position remain TO BE CONFIRMED.
Control modes: DMX512 / sound / auto / master-slave

Planning this product into your project

Start with the visual task and the distance from this fixture to the stage or subject. Compare its documented optics, movement, colour and control functions against that position in the lighting plan.

Product configuration

Movement: Pan 540 degrees / tilt travel TO BE CONFIRMED / fine channels
Product: 200W LED Module Beam Light with RGB Ring
Frost / rainbow: Independent frost and rainbow/color-effect insertion
Focus: Motorized focus verified by current fixture mapping
Dimming / strobe: 0-100% dimming; exact strobe frequency in Hz TO BE CONFIRMED
Environment: IP20 / -10 to 50 degrees C
Packing: 54 x 29 x 37.5 cm / gross weight 9.2 kg

Optical performance

Rated power: 200W
Light source: LED module; exact brand, model and actual source wattage TO BE CONFIRMED
Color wheel: 13 colors + white
Fixed gobos: COUNT TO BE CONFIRMED (11/12 source conflict)
Prism system: Single motorized prism; exact facet specification TO BE CONFIRMED

Control and connections

DMX channels: 16CH DMX512
Input voltage: AC110-240V, 50/60Hz
Control modes: DMX512 / sound / auto / master-slave

Construction and dimensions

Size / weight: 28 x 18 x 46 cm / net weight TO BE CONFIRMED
Electrical protection: Use a grounded supply. Rated current and fuse value, type and position remain TO BE CONFIRMED.

What to confirm for your quotation

Provide the throw distance, mounting height and beam or coverage required.
Confirm the exact light source, optical functions and channel mode for the quoted variant.
Request relevant photometric data and a demonstration using the intended colour and zoom settings.
Check power, connectors, weight, protection rating and the included mounting accessories.

TECHNICAL REFERENCE

Product specifications.

Published product details. Ask our team about any configuration that is not listed.

200W LED Module Beam Light with RGB Ring technical specifications
Rated power	200W
Light source	LED module; exact brand, model and actual source wattage TO BE CONFIRMED
DMX channels	16CH DMX512
Movement	Pan 540 degrees / tilt travel TO BE CONFIRMED / fine channels
Product	200W LED Module Beam Light with RGB Ring
Input voltage	AC110-240V, 50/60Hz
Control modes	DMX512 / sound / auto / master-slave
Color wheel	13 colors + white
Fixed gobos	COUNT TO BE CONFIRMED (11/12 source conflict)
Prism system	Single motorized prism; exact facet specification TO BE CONFIRMED
Frost / rainbow	Independent frost and rainbow/color-effect insertion
Focus	Motorized focus verified by current fixture mapping
Dimming / strobe	0-100% dimming; exact strobe frequency in Hz TO BE CONFIRMED
Size / weight	28 x 18 x 46 cm / net weight TO BE CONFIRMED
Environment	IP20 / -10 to 50 degrees C
Packing	54 x 29 x 37.5 cm / gross weight 9.2 kg
Electrical protection	Use a grounded supply. Rated current and fuse value, type and position remain TO BE CONFIRMED.
