1000W LED Profile Moving Head with Framing Shutters, CMY + CTO
LED Profile Moving Head
A 1000W LED profile moving head with a four-in-one optical design: beam (2-6°), spot (10-48°) and wash (up to 52°) modes plus a framing system of four independent blades that each close fully and rotate 90°. It suits theatres, TV studios, concert halls and large events.
Independent CMY mixing, linear CTO from 2800K to 6000K, 5 colours, 6 fixed and 7 replaceable rotating gobos, an animation effect wheel, a reversible 8-facet prism and 0-100% frost. Dimming frequency adjusts from 1200 to 2400 Hz for flicker-free 4K camera work. 35 DMX512 channels with RDM.
Specification
| Light source | 1000W white LED |
|---|---|
| Rated power | 1150W, switching power supply |
| Input voltage | AC100-240V, 50/60Hz |
| Optics | Beam 2-6°; spot 10-48°; wash 0-52° |
| Framing system | 4 independent blades, each closes fully, system rotates 90° |
| Color mixing | Independent CMY + linear CTO 2800-6000K |
| Color wheel | 5 colours + white |
| Fixed gobos | 6 gobos + open |
| Rotating gobos | 7 replaceable glass gobos + open |
| Effects | Animation wheel (flame and water effects) |
| Prism | 8-facet, bidirectional rotation |
| Frost | Independent 0-100% linear frost |
| Dimming | 0-100% linear; 1200-2400 Hz adjustable, flicker-free on 4K cameras |
| Pan / Tilt | 540° / 270°, 16-bit |
| Control modes | DMX512, RDM |
| DMX channels | 35CH |
| Connections | 3-pin XLR DMX |
| Display | LCD, English / Chinese |
| Protection rating | IP20 (indoor) |
| Product size | 79.5 x 36.5 x 50.5 cm |
| Net weight | 30 kg |
