TH1240-100 Hybrid Beam + Bee-Eye Moving Head

Name: TH1240-100 Hybrid Beam + Bee-Eye Moving Head
Brand: YL Light

TH1240-100 Hybrid Beam + Bee-Eye Moving Head is a stage lighting catalogue item in the hybrid beam / bee-eye moving head light category. Reference specifications list dmx channels: 28 / 140 / 20CH note-claimed; no table or standalone fixture library supplied; movement: 540-degree pan / 270-degree tilt / 16-bit fine positioning. Confirm the exact fixture version, specifications and current supply details before ordering.

WHATSAPPRequest a Quote

View specifications

Electrical protection: Grounded Class I supply required. Rated current, fuse value and fuse-holder location: TBC.
Size / weight: Product size, net weight and gross weight: TBC

Planning this product into your project

Start with the visual task and the distance from this fixture to the stage or subject. Compare its documented optics, movement, colour and control functions against that position in the lighting plan.

Product configuration

Movement: 540-degree pan / 270-degree tilt / 16-bit fine positioning
Strobe: 0.3-25 flashes/second; synchronous and asynchronous/random claims
Product: TH1240-100 Hybrid Beam + Bee-Eye Moving Head
Dimming: 0-100% linear; 1.2-25kHz adjustable-frequency claim
Environment: IP20 base fixture; optional rain-cover claim up to IP44

Control and connections

DMX channels: 28 / 140 / 20CH note-claimed; no table or standalone fixture library supplied
Input voltage: AC100-240V, 50/60Hz

Construction and dimensions

Size / weight: Product size, net weight and gross weight: TBC
Electrical protection: Grounded Class I supply required. Rated current, fuse value and fuse-holder location: TBC.

What to confirm for your quotation

Provide the throw distance, mounting height and beam or coverage required.
Confirm the exact light source, optical functions and channel mode for the quoted variant.
Request relevant photometric data and a demonstration using the intended colour and zoom settings.
Check power, connectors, weight, protection rating and the included mounting accessories.

TECHNICAL REFERENCE

Product specifications.

Published product details. Ask our team about any configuration that is not listed.

TH1240-100 Hybrid Beam + Bee-Eye Moving Head technical specifications
DMX channels	28 / 140 / 20CH note-claimed; no table or standalone fixture library supplied
Movement	540-degree pan / 270-degree tilt / 16-bit fine positioning
Input voltage	AC100-240V, 50/60Hz
Strobe	0.3-25 flashes/second; synchronous and asynchronous/random claims
Product	TH1240-100 Hybrid Beam + Bee-Eye Moving Head
Dimming	0-100% linear; 1.2-25kHz adjustable-frequency claim
Size / weight	Product size, net weight and gross weight: TBC
Environment	IP20 base fixture; optional rain-cover claim up to IP44
Electrical protection	Grounded Class I supply required. Rated current, fuse value and fuse-holder location: TBC.
