LEDT12 12 x 40W RGBW Moving Pixel Bar

Name: LEDT12 12 x 40W RGBW Moving Pixel Bar
Brand: YL Light

LEDT12 12 x 40W RGBW Moving Pixel Bar is a stage lighting catalogue item in the moving pixel bar light category. Reference specifications list rated power: 500W max English manual; 600W max Chinese manual - source conflict; light source: 12 x 40W RGBW 4-in-1 main LEDs; auxiliary pixel quantity TBC. Confirm the exact fixture version, specifications and current supply details before ordering.

WHATSAPPRequest a Quote

View specifications

Light source: 12 x 40W RGBW 4-in-1 main LEDs; auxiliary pixel quantity TBC
Protection: IP20; indoor use
Size / weight: Product dimensions TBC; 15kg net

Planning this product into your project

Select this effect around the visual role it needs to perform and its position in the rig. Pixel mapping, movement and channel modes should be confirmed for the exact fixture rather than inferred from an effect video.

Product configuration

Movement: 220-degree vertical tilt; 16-bit; tilt reverse and feedback settings
Product: LEDT12 12 x 40W RGBW Moving Pixel Bar
Strobe: 1-20Hz English channel table; 1-25Hz Chinese parameter block
Dimming: 0-100%; linear, square, inverse-square and S-curve
Packing: 107 x 36 x 19cm; 16kg gross; one unit
Auxiliary LEDs: English and Chinese source descriptions conflict; final production BOM required

Optical performance

Rated power: 500W max English manual; 600W max Chinese manual - source conflict
Light source: 12 x 40W RGBW 4-in-1 main LEDs; auxiliary pixel quantity TBC

Control and connections

DMX channels: 27CH library-verified; 28/67CH manual-documented; separate M1204A 18CH profile TBC
Input voltage: AC100-240V 50/60Hz English manual; AC90-240V Chinese manual - final nameplate required

Construction and dimensions

Protection: IP20; indoor use
Size / weight: Product dimensions TBC; 15kg net
Electrical protection: Rated current, fuse value and fuse-holder location: TBC.

What to confirm for your quotation

Describe the desired effect, viewing distance and fixture positions.
Confirm the controllable sections, movement functions and selected channel mode.
Check console profiles, addressing, power distribution and cable routing for the planned quantity.
Confirm mounting, operating limits and any restrictions in the venue.

TECHNICAL REFERENCE

Product specifications.

Published product details. Ask our team about any configuration that is not listed.

LEDT12 12 x 40W RGBW Moving Pixel Bar technical specifications
Rated power	500W max English manual; 600W max Chinese manual - source conflict
Light source	12 x 40W RGBW 4-in-1 main LEDs; auxiliary pixel quantity TBC
DMX channels	27CH library-verified; 28/67CH manual-documented; separate M1204A 18CH profile TBC
Movement	220-degree vertical tilt; 16-bit; tilt reverse and feedback settings
Product	LEDT12 12 x 40W RGBW Moving Pixel Bar
Input voltage	AC100-240V 50/60Hz English manual; AC90-240V Chinese manual - final nameplate required
Strobe	1-20Hz English channel table; 1-25Hz Chinese parameter block
Dimming	0-100%; linear, square, inverse-square and S-curve
Protection	IP20; indoor use
Size / weight	Product dimensions TBC; 15kg net
Packing	107 x 36 x 19cm; 16kg gross; one unit
Auxiliary LEDs	English and Chinese source descriptions conflict; final production BOM required
Electrical protection	Rated current, fuse value and fuse-holder location: TBC.
