LA-RAK II AVB Touring Rack

Model

LA-RAK II AVB Touring Rack

Product category

Amplifiers & Processing

AC presence 3 x dual LEDs

Left: US AC input / right: EU AC input

AC presence 3 x dual LEDs

Left: US AC

input / right

EU AC input

Compatible products

KS218SUB Dual 18-Inch Reference Subwoofer, KS218SUB Active Dual 18-Inch Reference Subwoofer

Function / configuration

Output Power Up to 40 000 W at 2,7 ohms

Function / configuration

Power supply Three-phase 32 A IEC in/link

Function / configuration

30 A NEMA for 110 V

Function / configuration

Inputs Milan-AVB, AES/EBU, Analog

Function / configuration

Amplification 3 LA12X Amplified controllers

Function / configuration

Network 2 LS10 AVB switches

Function / configuration

Misc 2 doors, cables and 2 coupling bars

Function / configuration

Analog input / link 2 x 19-point CA-COM

Function / configuration

AES/EBU 3 x female Neutrik XLR3 (IN) / 3 x

Function / configuration

Analog input / link (rear) 6 x male

Function / configuration

AES/EBU (rear) 3 x female Neutrik XLR3

Function / configuration

(IN) / 3 x male Neutrik XLR3 (LINK)

Function / configuration

AC input (US) 30 A - NEMA L21-30P (3P+N+E)

Function / configuration

AC input/link out (EU) 32 A - IEC 60309

Function / configuration

32 A - IEC 60309 (3P+N+E) female outlet

Function / configuration

AC auxiliary output (US) NEMA 5-15 female

Function / configuration

AC auxiliary output (EU) Type F «Schuko»

Function / configuration

Protection 10 A type C circuit breaker (AUX

Function / configuration

AC output for LA12X (rear) 3 x power cords

Function / configuration

fitted with 32 A Neutrik powerCON connectors

Function / configuration

AC input selector switch (rear) Switch

Function / configuration

AC output for LS10 (rear) 2 x IEC 60320-1

Function / configuration

Cables

Function / configuration

labeled cables, 1.10 m / 3.61 ft

Function / configuration

2 ANALOG XLR3 male/female labeled cables, 0.55

Function / configuration

cables, 1.10 m / 3.61 ft

Function / configuration

2 AES3 XLR3 male/female labeled cables

Function / configuration

0.55 m / 1.8 ft

Function / configuration

Network 3 CAT7 red Ethernet labeled cables

Function / configuration

1 m / 3 ft

Function / configuration

3 CAT7 black Ethernet labeled cables,1 m /

Function / configuration

2 RJ45 blockout cover for LA-PANEL II

Function / configuration

Rigging and handling

Function / configuration

Storage and transportation 2 coupling bars

Function / configuration

1 dolly board

Function / configuration

Rack Units 9 RU

Function / configuration

AES/EBU 3 x female Neutrik XLR3 (IN) / 3 x male Neutrik XLR3 (LINK)

Function / configuration

Analog input / link (rear) 6 x male Neutrik XLR3 (IN 1 to IN 6)

Function / configuration

AES/EBU (rear) 3 x female Neutrik XLR3 (IN) / 3 x male Neutrik XLR3 (LINK)

Function / configuration

AC input (US) 30 A - NEMA L21-30P (3P+N+E) male outlet

Function / configuration

AC input/link out (EU) 32 A - IEC 60309 (3P+N+E) male outlet

Function / configuration

AC auxiliary output (US) NEMA 5-15 female outlet (AUX US MODE)

Function / configuration

AC auxiliary output (EU) Type F «Schuko» female outlet (AUX EU MODE)

Function / configuration

Protection 10 A type C circuit breaker (AUX L3)

Function / configuration

AC output for LA12X (rear) 3 x power cords fitted with 32 A Neutrik powerCON connectors

Function / configuration

AC input selector switch (rear) Switch between EU MODE and US MODE

Function / configuration

AC output for LS10 (rear) 2 x IEC 60320-1 type C13 female outlets (AUX L3)

Function / configuration

Analog 6 ANALOG OUT XLR3 male/female labeled cables, 1.10 m / 3.61 ft

Function / configuration

2 ANALOG XLR3 male/female labeled cables, 0.55 m / 1.8 ft

Function / configuration

AES / EBU 3 AES3 OUT XLR3 male/female labeled cables, 1.10 m / 3.61 ft

Function / configuration

3 AES3 LINK XLR3 male/female labeled cables, 1.10 m / 3.61 ft

Function / configuration

2 AES3 XLR3 male/female labeled cables, 0.55 m / 1.8 ft

Function / configuration

Network 3 CAT7 red Ethernet labeled cables, 1 m / 3 ft

Function / configuration

3 CAT7 black Ethernet labeled cables,1 m / 3 ft

Weight: 101.5 kg / 223.8 lb (with content)
