V8–V28P Line Array — product photo 1

YL Light YL-B&B Line Array Systems

V8–V28P Line Array

A compact 3-way line array with dual 10-inch low-frequency drivers and 80° × 10° coverage.

WHATSAPPRequest a Quote

View specifications

Maximum SPL: 139 dB
Bandwidth (−5 dB): 67 Hz – 19 kHz
Weight: 33 kg / 73 lb

Product identification

Model: V8–V28P Line Array
Product category: Line arrays

Technical specifications

Configuration: Compact line array, 3-way
Maximum SPL: 139 dB
Bandwidth (−5 dB): 67 Hz – 19 kHz
Low-frequency drivers: 2 × 10″
Mid-frequency drivers: 1 × 8″
High-frequency drivers: 2 × 1.4″ compression drivers
Coverage / directivity: H: 80° | V: 10°
Nominal impedance: 8 Ω

Physical specifications

Weight: 33 kg / 73 lb
Dimensions (H × W × D): 310 × 700 × 440 mm

Compatibility and deployment

Function / configuration: A compact 3-way line array with dual 10-inch low-frequency drivers and 80° × 10° coverage.

TECHNICAL REFERENCE

Product specifications.

Published product details. Ask our team about any configuration that is not listed.

V8–V28P Line Array technical specifications
Configuration	Compact line array, 3-way
Maximum SPL	139 dB
Bandwidth (−5 dB)	67 Hz – 19 kHz
Low-frequency drivers	2 × 10″
Mid-frequency drivers	1 × 8″
High-frequency drivers	2 × 1.4″ compression drivers
Weight	33 kg / 73 lb
Coverage / directivity	H: 80° \| V: 10°
Dimensions (H × W × D)	310 × 700 × 440 mm
Nominal impedance	8 Ω

Downloads

Product documents are being prepared. Contact YL for the current information for V8–V28P Line Array.

Request product documents

System accessories

Contact YL to confirm the available accessories and the exact configuration for V8–V28P Line Array.

Ask about compatible accessories
