S-2000 Waterproof Moving Head Strobe Light

Name: S-2000 Waterproof Moving Head Strobe Light
Brand: YL Light

S-2000 Waterproof Moving Head Strobe Light is a stage lighting catalogue item in the led par / audience light category. Reference specifications list strobe panel led type: 1.5W RGB 3in1 LEDs; strobe panel led count: 504. Confirm the exact fixture version, specifications and current supply details before ordering.

WHATSAPPRequest a Quote

View specifications

Net weight: 13.0 kg
Gross weight: 16.0 kg

Planning this product into your project

For a wash or area-lighting position, establish the coverage and colour required across the subject. Compare the listed optics and control functions with the working distance and the way the fixtures will be positioned.

Product configuration

Strobe panel LED type: 1.5W RGB 3in1 LEDs
Strobe panel LED count: 504
Strobe panel LED segments: 14 (2 x 7)
Strobe tube LED type: 5W 6500K LEDs
Strobe tube LED count: 280
Strobe tube LED segments: 28 (2 x 14)
Movement resolution: 8–16 Bit
Tilt: 185°
RDM: Bidirectional communication
Dimmer: 0–100% electronic
Shutter: Electronic, max. 20 Hz
Internal effects: LED Macro Effects
Art-Net connection: RJ45 In/Out
Mains voltage: 100–240V AC / 50–60Hz
Operating position: Any
Safety wire attachment: Foldout eyelets
Folding clamps: Optional
Length: 482 mm / 18.9 in

Optical performance

Strobe panel LED colors: RGB
Strobe tube LED colors: Cool-White
Power: 1800W
Housing color: Black

Control and connections

Control modes: 8CH / 18CH / 25CH / 95CH / C 8CH / C 11CH / C 13CH / C 24CH / C 30CH / C 47CH / C 68CH / C 74CH / C 97CH
Display: Illuminated graphic LCD Touch Screen
Control protocol: USITT DMX-512, RDM, Art-Net, sACN
Wireless DMX: 2.4 GHz W-DMX (optional)
Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out
Power input: Seetronic PowerCON TRUE1 In

Construction and dimensions

Cooling: Temperature controlled, overheating protection
Maximum ambient temperature: 30°C / 86°F, 50°C / 122°F
Mounting: Omega-Bracket (Support arm side hanging)
Width: 178 mm / 9.0 in
Height (head horizontal): 243 mm / 9.5 in
Net weight: 13.0 kg
Gross weight: 16.0 kg
Packing size: 56 x 43 x 25 cm

What to confirm for your quotation

Provide the subject dimensions, throw distance, fixture spacing and mounting height.
Confirm beam or zoom range, colour channels, dimming and any supported pixel control.
For faces or cameras, request relevant colour-quality and flicker data for the intended settings.
Verify supply, connectors, weight and environmental requirements for the actual location.

TECHNICAL REFERENCE

Product specifications.

Published product details. Ask our team about any configuration that is not listed.

S-2000 Waterproof Moving Head Strobe Light technical specifications
Strobe panel LED type	1.5W RGB 3in1 LEDs
Strobe panel LED count	504
Strobe panel LED colors	RGB
Strobe panel LED segments	14 (2 x 7)
Strobe tube LED type	5W 6500K LEDs
Strobe tube LED count	280
Strobe tube LED colors	Cool-White
Strobe tube LED segments	28 (2 x 14)
Movement resolution	8–16 Bit
Tilt	185°
Control modes	8CH / 18CH / 25CH / 95CH / C 8CH / C 11CH / C 13CH / C 24CH / C 30CH / C 47CH / C 68CH / C 74CH / C 97CH
Display	Illuminated graphic LCD Touch Screen
Control protocol	USITT DMX-512, RDM, Art-Net, sACN
RDM	Bidirectional communication
Wireless DMX	2.4 GHz W-DMX (optional)
Cooling	Temperature controlled, overheating protection
Dimmer	0–100% electronic
Shutter	Electronic, max. 20 Hz
Internal effects	LED Macro Effects
Signal connection	Seetronic IP65 XLR 5-Pin or 3-Pin In/Out
Power input	Seetronic PowerCON TRUE1 In
Art-Net connection	RJ45 In/Out
Mains voltage	100–240V AC / 50–60Hz
Power	1800W
Maximum ambient temperature	30°C / 86°F, 50°C / 122°F
Operating position	Any
Mounting	Omega-Bracket (Support arm side hanging)
Safety wire attachment	Foldout eyelets
Folding clamps	Optional
Housing color	Black
Length	482 mm / 18.9 in
Width	178 mm / 9.0 in
Height (head horizontal)	243 mm / 9.5 in
Net weight	13.0 kg
Gross weight	16.0 kg
Packing size	56 x 43 x 25 cm
