6-Head Double-Sided Infinite Rotation Tornado Bar Light

Moving Head Bar Light

A six-head double-sided tornado bar: the heads rotate endlessly, with 40W RGBW beams on one side and gold, RGB and white pixel faces on the other, so one fixture switches between beams, blinder washes and pixel chases.

Single-point control of 12 RGBW, 40 RGB, 72 warm-white and 20 white segments, 1-30 Hz strobe, RDM, and DMX512 in 17, 54, 90 or 354 channels. 800W; 18.25 kg.

DOWNLOAD FILE
WHATSAPPRequest a QuoteMoving Head Bar Lights

Specification

6-Head Double-Sided Infinite Rotation Tornado Bar Light — Specification
Light source12 x 40W 5060 RGBW LEDs
Auxiliary LEDs432 x 2W dual-colour gold + 480 x 0.25W 5050 RGB + 240 x 0.5W 5730 white
Rated power800W
Input voltageAC100-240V, 50/60Hz
Pixel control12 RGBW + 40 RGB + 72 WY + 20 W segments, single-point control
FeaturesDouble-sided heads, infinite rotation
Dimming0-100% linear
Strobe1-30 Hz
Control modesDMX512, RDM, auto, master-slave, sound-active
DMX channels17 / 54 / 90 / 354CH
ConnectionsDMX in / out, power in / out
Protection ratingIP20 (indoor)
Operating temperature-30°C to 50°C
Product size41.6 x 68.7 x 15.7 cm
Net weight18.25 kg

Download

Original technical file - Double headed infinite tornadoEnglishPDFUser manual (Chinese)ChinesePDF
