380 BEAM IP Outdoor IP66 Moving Head Beam Light — Round Fan Version
Outdoor Moving Head Beam Light
The round-fan version of the 380 BEAM IP outdoor moving head beam light, with a concentric round rear fan grille. It shares the IP66 die-cast housing and the USHIO NSLU6C lamp: a 1.7° beam, 14 colours, 13 gobos, 8-facet and 24-facet prisms, motorized zoom and frost.
Waterproof power and DMX connectors and 16-channel DMX512 control with RDM make it a direct match for 380 BEAM IP rigs on festival, stadium and outdoor stages.
Specification
| Light source | USHIO NSLU6C lamp |
|---|---|
| Rated power | 550W |
| Input voltage | AC100-240V, 50/60Hz |
| Beam angle | 1.7° |
| Front lens | 160 mm |
| Color wheel | 14 colours + open |
| Fixed gobos | 13 gobos + open |
| Prism | 8-facet and 24-facet |
| Zoom | Motorized zoom |
| Frost | Frost filter |
| Strobe | 1-20 Hz |
| Dimming | 0-100% smooth |
| Pan / Tilt | 540° / 270° |
| Control modes | DMX512, RDM |
| DMX channels | 16CH |
| Connections | Waterproof power in / out; waterproof DMX in / out |
| Housing | Full die-cast aluminium; concentric round rear fan grille |
| Protection rating | IP66 |
| Product size | 631 x 403 x 289 mm |
